Introduce Integrate Electric Power and Pneumatic Rotary Union for Industry System For You

Funciton Slip Ring
November 26, 2025
Categoria di collegamento: unione rotatoria pneumatica
Chiacchierare Contattici
Tag:
#unione rotatoria pneumatica #unione rotatoria ad alta pressione #sindacati rotatori della parte girevole
Breve: In this video, we provide an informative overview of the QCN01M5-25S integrated electric power and pneumatic rotary union. You will see how this device combines electrical circuits and pneumatic channels, learn about its customizable features, and discover its applications in automated machinery and testing equipment. Gain concise insights into the features that matter most for real-world use.
Caratteristiche del prodotto correlate:
  • Offers different sealing forms to suit various application requirements.
  • Integrates design to combine various signals, data, medium, and power transmission.
  • Allows for customized dimensions to fit specific system needs.
  • Features easy installation and requires no maintenance during operation.
  • Supports 25 circuits of electric power at 2A each with a rating voltage of 0-220 VAC/VDC.
  • Includes one pneumatic channel with M5*0.8 connection and tube Ø4 for air or pneumatic media.
  • Operates at speeds from 0 to 30 rpm with a working temperature range of -20°C to +80°C.
  • Provides IP51 protection grade and uses precious metal and aluminium alloy materials.
Domande frequenti:
  • What is the QCN01M5-25S integrated rotary union designed for?
    The QCN01M5-25S is designed for applications requiring simultaneous transmission of electric power and pneumatic or hydraulic media, such as in automated machines, turntable testing, and medical equipment.
  • Can the dimensions and specifications of this integrated rotary union be customized?
    Yes, dimensions can be customized, and options are available for circuits, voltage, current, signals, data, medium, contact/housing materials, protection grade, working speed, and temperature.
  • What are the key electrical specifications for the power transmission part?
    It features 25 circuits at 2A each, a rating voltage of 0-220 VAC/VDC, dielectric strength of ≥500VAC@50Hz, and isolation resistance of ≥500MΩ@500VDC.
  • What pneumatic capabilities does the rotary union provide?
    It includes one pneumatic channel with an M5*0.8 connection and tube Ø4, supporting a pressure range from -100KPa to 0.5MPa and a rotary torque of ≤1N*m.
